Threshold Weighted Continuous Ranked Probability Score (twCRPS) for ensembles

twCRPS can be used to evaluate ensembles while emphasising extremes or a range of important thresholds. Sometimes CRPS may mask performance around extremes and it may be desirable to use a threshold weighted score such as twCRPS. If you haven’t done so, we recommend working through the CRPS for forecasts expressed as CDFs and CRPS for ensemble forecasts tutorials before working through this tutorial. Note that the crps_cdf function has threshold weighting built into it, but the crps_for_ensemble does not. This tutorial will demonstrate how to calculate a threshold weighted CRPS for ensembles.

Overview and graphical illustration of twCRPS

We will begin by illustrating how the twCRPS for ensembles is calculated, first by defining the equation and then with a graphical representation. The emperical twCRPS for ensembles is defined as

\[\text{twCRPS}(F_{\text{ens}}, y; v) = \frac{1}{M} \sum_{m=1}^{M} \left| v(x_m) - v(y) \right| - \frac{1}{2M^2} \sum_{m=1}^{M} \sum_{j=1}^{M} \left| v(x_m) - v(x_j) \right|\]

where - \(M\) is the number of ensemble members, - \(y\) is the observation, - \(x_m\) is the forecast of a single ensemble member, - \(x_j\) is also the forecast of a single ensemble member, and - \(v\) is a ‘chaining function’.

The chaining function \(v\) is an anti-derivative of the threshold weight function \(w\), which is a non-negative function that assigns a weight to each threshold value.

For example, if we wanted to assign a threshold weight of 1 to thresholds above threshold \(t\) and a threshold weight of 0 to thresholds below \(t\), our threshold weight function would be \(w(x) = \mathbb{1}{(x > t)}\), where \(\mathbb{1}\) is the indicator function which returns a value of 1 if the condition is true and 0 otherwise. A chaining function would then be \(v(x) = \text{max}(x, t)\).

Let’s now visualise what the weighting and chaining functions if we were to set \(t=25\) for weighting an upper tail. Let’s assume that we are working with rainfall data with mm as the units.

import plotly.graph_objects as go
import numpy as np
from plotly.subplots import make_subplots

x = np.linspace(0, 100, 400)
t = 25

# Calculate w(x)
w_x = np.where(x > t, 1, 0)
# Calculate v(x)
v_x = np.maximum(x, t)

fig = make_subplots(
    rows=2,
    cols=1,
    subplot_titles=("Weight function: w(x) = 1(x>t)", "Chaining function: v(x) = max(x, t)"),
    vertical_spacing=0.15,
)
fig.add_trace(go.Scatter(x=x, y=w_x, mode="lines", name="w(x) = 1(x>t)", showlegend=False), row=1, col=1)
fig.add_trace(go.Scatter(x=x, y=v_x, mode="lines", name="v(x) = max(x, t)", showlegend=False), row=2, col=1)

fig.update_layout(
    xaxis_title="x (mm)",
    yaxis_title="w",
    xaxis2_title="x (mm)",
    yaxis2_title="v",
    showlegend=True,
    width=600,
    height=600,
    margin=dict(l=20, r=20, t=40, b=60),
)
fig.show()
